SRP-X500P RS-232C Interface Manual
2.1.17 SCENE RECALL PARAMETER REQUEST : 0x52 0x52 0x43 0x4C
(‘RRCL’)
This command is used to read the recalled scene number from the SRP-X500P.
Packet format
0x52 0x52 0x43 0x4C 0x0D
Return packet format
When the SRP-X500P receives the command successfully, the parameter is returned together with an ACK
(0x41(‘A’)) in the order shown below.
0x41
“ parameter” 0x0D
♦ Parameter
The parameter consists of 1 byte of data.
Byte Parameter
1st SCENE No.
• SCENE No. (1st byte)
Shows the recalled scene number, as shown in the following table.
SCENE No.
None 0x30 (‘0’)
1 0x31 (‘1’)
2 0x32 (‘2’)
3 0x33 (‘3’)
4 0x34 (‘4’)
5 0x35 (‘5’)
6 0x36 (‘6’)
7 0x37 (‘7’)
8 0x38 (‘8’)
Example
When no scene has been recalled:
0x41 0x30 0x0D
(‘A 0 CR’)
Page 19/43
