GP Series Portable Chillers Chapter 7: Appendix 38 of 44
7-3 Specifications
Air-Cooled Portable Chillers
Nominal operating parameters for air-cooled models are 50ºF (10ºC) leaving water temperature at 2.4
gpm per ton (9.1 lpm per 3.517 kW) with 95ºF (35ºC) ambient air. For 50 Hz applications, multiply
capacity by 0.83. Nominal 60 Hz capacity flow rate must be maintained.
G-PAC-20
PERFORMANCE (NOMINAL DESIGN CONDITIONS)
COOLING CAPACITY 4.72 TONS ALTITUDE SEA LEVEL
COOLANT SUPPLY TEMPERATURE 50 °F COMPRESSOR POWER 4976 WATTS
AMBIENT AIR TEMPERATURE 95 °F EER 11.39 BTU/WATT
COOLANT WATER CONDENSER AIR FLOW 4230 CFM
COOLANT FLOW 11 GPM SOUND POWER LEVEL 86 dBA
UNIT PRESSURE DROP 7 PSID SOUND PRESSURE LEVEL @ 1 METER dBA
OPERATING PARAMETERS
COOLANT SUPPLY TEMPERATURE 20-80 °F COOLANT FLOW GPM
AMBIENT AIR TEMPERATURE 60-115 °F MINIMUM LOAD 0.944 TONS
SPECIFICATIONS
COMPRESSOR SCROLL EVAPORATOR FILTER 20 MESH
COOLANT PUMP
STAINLESS STEEL
CENTRIFUGAL
COOLANT CIRCUIT NON-FERROUS
EVAPORATOR BRAZED PLATE CAPACITY CONTROL HOT GAS BYPASS
CONDENSER ALUMINUM REFRIGERANT 3 LBS R-410A
CONDENSER FANS
24 INCH
AXIAL
FRAME GALVANIZED STEEL
CONDENSER FAN MOTOR 1/2 HP OAO, 1140 RPM PANELS POWDER COATED STEEL
RESERVOIR 20 GALLON POLYETHYLENE WEIGHT (OPERATING) 690 LBS
POWER 460V/3PH/60HZ WEIGHT (SHIPPING) 520 LBS
CONTROL CIRCUIT 120 VDC ELECTRICAL ENCLOSURE NEMA 12
COMPRESSOR FULL LOAD AMPS 10.7 AMPS CONTROL MICROPROCESSOR
G-PAC-30
PERFORMANCE (NOMINAL DESIGN CONDITIONS)
COOLING CAPACITY 7.52 TONS ALTITUDE SEA LEVEL
COOLANT SUPPLY TEMPERATURE 50 °F COMPRESSOR POWER 7634 WATTS
AMBIENT AIR TEMPERATURE 95 °F EER 11.82 BTU/WATT
COOLANT WATER CONDENSER AIR FLOW 6343 CFM
COOLANT FLOW 18 GPM SOUND POWER LEVEL 92 dBA
UNIT PRESSURE DROP 7 PSID SOUND PRESSURE LEVEL @ 1 METER dBA
OPERATING PARAMETERS
COOLANT SUPPLY TEMPERATURE 20-80 °F COOLANT FLOW GPM
AMBIENT AIR TEMPERATURE 60-115 °F MINIMUM LOAD 1.504 TONS
SPECIFICATIONS
COMPRESSOR SCROLL EVAPORATOR FILTER 20 MESH
COOLANT PUMP
STAINLESS STEEL
CENTRIFUGAL
COOLANT CIRCUIT NON-FERROUS
EVAPORATOR BRAZED PLATE CAPACITY CONTROL HOT GAS BYPASS
CONDENSER ALUMINUM REFRIGERANT 4 LBS R-410A
CONDENSER FANS
24 INCH
AXIAL
FRAME GALVANIZED STEEL
CONDENSER FAN MOTOR 1 HP OAO, 1140 RPM PANELS POWDER COATED STEEL
RESERVOIR 20 GALLON POLYETHYLENE WEIGHT (OPERATING) 870 LBS
POWER 460V/3PH/60HZ WEIGHT (SHIPPING) 700 LBS
CONTROL CIRCUIT 120 VDC ELECTRICAL ENCLOSURE NEMA 12
COMPRESSOR FULL LOAD AMPS 16.4 AMPS CONTROL MICROPROCESSOR
