40
SPECIFICATIONS
VIDEO CAMERAS
GENERAL
Mass Approx 870 g (1lb. 14 oz) Approx 440 g (16 oz)
Dimensions (W x H x D) Base: 147 x 111 x 148 mm Base: 121 x 123 x 106 mm
(5 3 ⁄ 4 " x 4 3 ⁄ 8 " x 5 7 ⁄ 8 ") (4 3 ⁄ 4 " x 4 7 ⁄ 8 " x 4 1 ⁄ 8 ")
Bubble: 94 mm (3 3 ⁄ 4 ") (ø) Bubble: 91 mm (3 5 ⁄ 8 ") (ø)
Input voltage AC 24 V/DC 12 V AC 24 V/DC 12 V
Power consumption 3.5 W 3.3 W
Operating temperature -20° C to +50 °C (-4° F to +122° F)
Operating humidity 20 % to 80 % (non condensing)
Weather proof IP66 —
CAMERA
Image device 1⁄4 type Interline Transfer SuperHAD CCD
Picture Elements (H x V) 752 x 582
Built-in lens f = 3.0 to 8.0 mm, F1.0 Auto iris
Auto Gain Control ON (Turbo mode)/OFF switchable
Lens mount CS Mount
View angle (D, H, V) (H): 66.6 ° (wide), 26.9 ° (tele) (V): 49.3° (wide), 20.1° (tele)
Focus length Minimum object distance: 0.2 m
White Balance ATW
Signal system/ PAL color system
scanning system
Sync. system
Internal (DC 12 V/AC 24 V) /Line lock (AC 24 V only) switchable
External sync. AC line lock (for AC 24 V)
V-phase control ±90 °
Horizontal resolution 480 TV lines
S/N ratio More than 50 dB (AGC OFF, weight ON)
Min. illumination Colour: 0.9 lux 0.9 lux (AGC ON)
(Turbo AGC ON) (F1.0, 50 IRE, AGC ON)
B&W: 0.2 lux
(F1.0, 50 IRE, AGC ON)
OPTIONAL ACCESSORIES
YT-ICB73V YT-ICB43V
In-ceiling bracket In-ceiling bracket
SSC-CD73VP SSC-CD43VP
