26
SPECIFICATIONS
NETWORK VIDEO CAMERAS
SNC-P1 SNC-P5
GENERAL
Mass Approx. 225 g (8 oz) Camera: approx. 380 g (13 oz)
Stand: approx. 360 g (13 oz)
Dimensions (W x H x D) 99.5 x 35 x 138.5 mm Camera: 130 x 130 x 110 mm
(4 x 1 7 ⁄ 16 x 5 1 ⁄ 2 inches) (5 1 ⁄ 8 x 5 1 ⁄ 8 x 4 3 ⁄ 8 inches)
without projection Stand: 130 x 178 x 142 mm
(5 1 ⁄ 8 x 7 1 ⁄ 8 x 5 5 ⁄ 8 inches)
Power requirements DC 12 V DC 12 V
Power consumption 3.5 W 6.2 W
Operating temperature 0 to +35 °C (32 to 95 °F) 0 to +35 °C (32 to 95 °F)
Storage temperature -20 to 60 °C (-4 to +140 °F)
Operating humidity 20 to 80 %, Non-condensing
Storage humidity 20 to 95 %, Non-condensing
CAMERA
Image device 1/4-type progressive scan CCD 1/4-type progressive scan CCD
Number of effective 659 x 494 (330K) 659 x 494 (H x V)
pixels
Electronic shutter
1 to 1/10000 s 1 to 1/10000 s
Exposure mode Auto, Shutter priority, Manual Auto, Shutter priority, Manual
White balance Auto, Indoor, Outdoor, One-push, Manual Auto, Indoor, Outdoor, One-push, Manual
Minimum illumination 3.0 lx 3.5 lx (AGC ON, F2.8, 30IRE)
LENS
Focal length f=3.8 mm f=3.4 mm, to 10.2 mm
Viewing angle Horizontal: 53.4°, Vertical: 40.0° Horizontal: 20 to 55.8°, Vertical: 15.1 to 43.3°
F-number F2.0 F2.8 (wide) to 3.9 (Tele)
Minimum object distance 50 cm 0.4m (wide end), 1.4m (Tele end)
SYSTEM/NETWORK
Compression format MPEG-4/JPEG selectable MPEG-4/JPEG selectable
Image size (H x V)
MPEG-4 mode
640 x 480, 480 x 360, 384 x 288, 640 x 480, 480x 360, 384 x 288,
320 x 240, 256 x 192, 160 x 120 320 x 240, 256 x 192, 160 x 120
JPEG mode 640 x 480, 480 x 360, 384 x 288, 640 x 480, 480x 360, 384 x 288,
320 x 240, 256 x 192, 160 x 120 320 x 240, 256 x 192, 160 x 120
Maximum frame rate
MPEG-4 mode Max. 30 f/s (320x240) Max. 30 fps, 320 x 240,
Max. 15 fps, 640 x 480
JPEG mode Max. 30 f/s (320x240) Max. 30 fps, 320 x 240,
Max. 18 fps, 640 x 480
Audio compression G.711 (64 Kbps)/G.726 (40, 32, 24, 16 Kbps) G.711 (64 Kbps)/G.726 (40, 32, 24, 16 Kbps)
Number of clients
MPEG-4 mode 10 clients 10 clients
JPEG mode 20 clients 20 clients
Protocols TCP/IP, UDP, RTP, RTCP, ARP, ICMP, HTTP, TCP/IP, ARP, ICMP, DHCP, DSN, HTTP, FTP,
FTP, SMTP, DHCP, DNS, NTP and PPPoE, SMTP, NTP, SNMP (MIB-2), RTP/RTCP, PPPoE
SNMP
INTERFACES
Ethernet 100Base-TX/10Base-T (RJ-45) 100Base-TX/10Base-T (RJ-45)
PC card slot — Compact Flash for storage or wireless
Video output Mini-jack Mini-jack (1.0 V p-p, 75 Ω, Sync negative)
Built-in microphone Electret condenser microphone Electret condenser microphone
(omni-directional)
External microphone input Mini-jack, Plug-in power, 2.2 kΩ, Mini-jack, 2.2 kΩ,
Unbalanced Unbalanced (RCA), 2.5 V
plug-in power
Line output Mini-jack Mini-jack, (mono), max output level: 1 Vms
Sensor in 1 2
Alarm out 1 1
Supplied accessories AC adaptor (x1) AC power adaptor MPA-AC1 (Sony) (x1)
CD-ROM (x1, setup program Power cord (x1)
and user guide) Stand (x1)
Stand (x1) Wall-mount (x1)
