34
SPECIFICATIONS
VIDEO CAMERAS
GENERAL
Mass 380 g (13 oz) 400g (14 oz)
Mass including front 460 g (1 lb 1 oz) 480g (1 lb 8 oz)
& rear covers
Dimensions (W x H x D)
60 x 53 x 124 mm (2 3 ⁄ 8 " x 2 1 ⁄ 8 " x 5")
Dimensions including 60 x 53 x 246 mm (2 3 ⁄ 8 " x 2 1 ⁄ 8 " x 9 3 ⁄ 4 ")
front and rear covers
Power requirements
AC 24 V ±10%, 50 Hz AC 220 V to 240 V
or DC 12 V ±10% ±10%, 50 Hz
Power consumption 4.0 W
Operating temperature -10 °C to 50 °C (14 °F to 122 °F)
Storage temperature -40 °C to 60 °C (-40 °F to 140 °F)
CAMERA
Image device 1/3 type Interline Transfer CCD with SuperExwave
Picture elements (H x V) 752 x 582
Auto Gain Control TURBO/OFF switchable
White Balance (WB) Auto White Balance Pro(ATW Pro) /Auto Wite Balance(ATW)
Lens mount CS
CCD IRIS ON/OFF switchable, 1/50 to 1/100,000 s
Backlight Compensation ON/OFF switchable
(BLC)
Video out
BNC, 1.0 Vp-p, 75 Ω, sync negative
Sensing area 1/3 type format (4.8 x 3.6 mm)
Signal system PAL standard
Sync system INT/Line Lock
Horizontal resolution 540 TV lines
S/N ratio More than 50 dB (AGC OFF, WEIGHT ON)
Minimum illumination Colour: 0.55 lx at F1.2 (50 IRE, AGC ON, Turbo mode)
B&W: 0.05 lx at F1.2 (50 IRE, AGC ON, Turbo mode)
Auto iris lens DC servo
SUPPLIED ACCESSORIES
Lens mount cap (1), Operating instructions (1), Front cover(1), Rear cover(1),
Screws (2), Power cable (1)
SSC-E473P SSC-E478P
