31
SPECIFICATIONS SPECIFICATIONS
NETWORK VIDEO RECORDERS AND SERVERS
GENERAL
Mass Approx. 12 kg (26 lb 7 oz) Approx. 13 kg (28 lb 11 oz)
Dimensions (W x H x D) 430 x 87 x 417 mm (17 x 3 1⁄2 x 16 1⁄2) excluding protrusions
Power requirement 100 to 127/200 to 240 V AC
Power consumption 1.93 A / 0.99 A 2.77 A / 1.39 A
Operating temperature 5 to 40 ºC (41 to 104 ºF)
Operating humidity 10 to 80% (non-condensing)
VIDEO/RECORDING
Number of IP Cameras 32 Max.
Supported
Video Compression
MPEG-4 or JPEG
Maximum Recording 240 fps
Rate* 1
HARD DISK DRIVES
Physical Capacity 500 GB (250 G x 2)
Interface Serial ATA
RAID Level/Recording Software RAID Hardware RAID (Hot Swappable
when set to RAID 5 or RAID 1)
Capacity (approx.) SPAN (Default): 460 GB RAID 5 (Default): 700 GB
RAID 1: 210 GB RAID 1: 460 GB
RAID 0: 940 GB
Network File System Supports NFS Version 3 protocol Supports NFS Version 3 protocol
(for NAS)
VIDEO INTERFACE
Monitor OUT #1 RGB connector x2 (Front and Rear Panel,
cannot be used simultaneously)
#2 RGB connector x1
Video Output S-Video x1
Analogue Composite OUT RCA-pin x2 (Front and Rear Panel, cannot be used simultaneously)
AUDIO INTERFACE
Mic IN Mini jack x1(front), x 1(rear)
Line OUT RCA-pin, L/R x1 stereo pair, (front and rear panel)
SENSOR/ALARM
Sensor IN 8-channel photo-coupler (DC3.3-24V)
Alarm OUT 8-channel relay (Max. 24V 1A)
OTHER INTERFACES
Ethernet 1000Base-T/100Base-TX/10Base-T x3 (automatic switching)
USB Front x2, Rear x2
Serial interface RS-232C x1 (for UPS)* 2
SUPPLIED ACCESSORIES
Front panel key, Installation guide, Remote control unit operation card,
Recovery CD, Manual/Tool/ Source codes CD, Rubber feet (4)
*1 Recording frame rates shown in the table represents the total frame rate per recorder unit when recording images at JPEG, Level
5 using the SNC-RZ30, and without live image monitoring.
*2 Please contact your local Sony sales office for a list of recommended UPS systems.
NSR-50 NSR-100
