33
SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS
VIDEO CAMERAS
GENERAL
Mass 500 g (1 lb. 2 oz)
Dimensions (W x H x D) 70 x 57 x 129 mm (2 7 ⁄ 8 " x 2 1 ⁄ 4 " x 5 1 ⁄ 8 ")
Power requirements AC 24 V ±10%, 50 Hz AC 220 V to 240 V
or DC 12 V ±10% ±10%, 50 Hz
Power consumption 5.8 W 5.6 W
Operating temperature -10 to 50 °C (-40 to 122 °F)
Storage temperature -40 to 60 °C (-40 to 140 °F)
CAMERA
Image device 1/3 type Interline Transfer CCD with DynaView technology
Number of effective 752 x 582
pixels (H x V)
Auto Gain Control
OFF/MANUAL/NORMAL/TURBO selectable
White balance mode ATW PRO/ATW/3200K/5600K/MANUAL/DUAL WB
Lens type CS
CCD iris 1/60 (1/50) to 1/10000 (8steps) OFF/MANUAL/
CCD IRIS selectabl
Back-Light DYNAVIEW/SPOT/WEIGHT/OFF switchable
Compensation (BLC)
Video out
1.0 Vp-p, BNC (1)
Day/Night mode COLOUR/AUTO/EXTERNAL/B&W
Activity detection ON / OFF switchable
Zone masking ON / OFF switchable (with Area setting function)
Variable Gamma OFF /SCENE1 /SCENE2/SCENE3/SCENE4 selectable
Camera Title Up to 24 characters ON / OFF switchable
Remote Control RS-485
Signal system PAL
Sync system Internal/External
Horizontal Resolution 480 TV lines
S/N ratio More than 50 dB (AGC OFF, Weight ON)
Minimum illumination Colour: 0.8 lux at F1.4( 50 IRE)
B/W: 0.07 lux at F1.4 (50 IRE)
Auto iris lens DC/video servo switchable
SUPPLIED ACCESSORIES
Lens mount cap (x1) Lens mount cap (x1)
Menu operations (x1) Menu operations (x1)
Operation manual (x1) Operation manual (x1)
AC power cable (x1)
SSC-DC593P SSC-DC598P
