SPECIFICATIONS
VIDEO CAMERAS
GENERAL
Mass 360 g (13 oz) 390 g (14 oz)
Dimensions (W x H x D) 60 x 54 x 120 mm (2 3 ⁄ 8 " x 2 1 ⁄ 4 " x 4 3 ⁄ 4 ")
Power requirements AC 24 V ±10%, 50 Hz or DC 12 V ±10% AC 220 V to 240 V ±10%, 50 Hz
Power consumption 2.5 W
Operating temperature -10 to 50 °C (14 to 122 °F)
Storage temperature -40 to 60 °C (-40 to 140 °F)
CAMERA
Image device 1/3 type Interline Transfer CCD
Picture elements (H x V) 500 x 582
Auto Gain Control ON/OFF (switchable)
Lens mount CS
CCD IRIS ON/OFF (switchable), 1/50 to 1/100,000 s
Back-Light Compensation ON/OFF switchable
(BLC)
Video out
1.0 Vp-p; 75Ohm, sync. negative
Sensing area 1/3 type format (4.8 x 3.6 mm)
Signal system CCIR standard
Sync. System INT/LL LL
Horizontal resolution 380 TV lines
S/N ratio More than 50 dB (AGC OFF, weight ON)
Minimum illumination 0.03 lux at F1.2 (30 IRE, AGC ON, Turbo mode)
0.06 lux at F1.2 (50 IRE, AGC ON, Turbo mode)
0.25 lux at F1.2 (100 IRE, AGC ON,Turbo mode)
Auto iris lens DC/video servo switchable
SUPPLIED ACCESSORIES
Lens mount cap (x1) Operation manual (x1)
SSC-M183CE SSC-M188CE
