Door Panel

MODELS UC-24R AND UC-24C(I)

Models UC-24R and UC-24C(I) can be fitted with a

custom overlay or stainless steel door front panel. A stain-

less steel door panel with tubular or pro handle is available

as a sales accessory. Installation of the stainless steel

panel will be required.

For the overlay application, a decorative door panel and

handle hardware must be provided. Refer to the chart for

panel specifications.

You can match your handle hardware with surrounding

cabinetry or use a Sub-Zero accessory handle. Handles

must be attached directly to the overlay panel.

BEVERAGE CENTER MODEL UC-24BG

Stainless steel model UC-24BG/S is shipped from the

factory with the stainless steel door panel and tubular or

pro handle in place. No panel installation is required.

For overlay model UC-24BG/O, a decorative frame door

panel must be provided to surround the glass. The inside

edges of the panel that will be visible through the glass

must be finished. Refer to the chart for panel specifica-

tions.

You may also use your own handle hardware to match sur-

rounding cabinetry. If you do not use the pre-drilled holes

on the door of the unit, you will need to attach the handle

directly to the overlay panel.

IMPORTANT NOTE:

For installations at or above 5,000'

(1524 m)

in altitude, a special high altitude glass door unit

must be ordered.

OUTDOOR MODEL UC-24RO

Model UC-24RO is shipped from the factory with the

stainless steel door panel and tubular or pro handle in

place. No panel installation is required.

IMPORTANT NOTE:

Model UC-24RO must be built into

cabinetry and cannot be used in a freestanding applica-

tion.

Undercounter Installation

9

subzero.com/specs

A solid panel must not be installed over the glass door,

as this may cause moisture to form behind the panel.

Panel Specifications

OVERLAY PANEL

W

H

UC-24R, UC-24BG, UC-24C(I)

23

3

/

4

"

(603)

30

1

/

16

"

(764)

RAILS AND STILES

W

UC-24BG

2

1

/

4

"

(57)

min

MAX PANEL WEIGHT

UC-24R and UC-24C(I)

20 lbs

(9 kg)

UC-24BG

10 lbs

(5 kg)

MIN PANEL THICKNESS

Overlay Panels

5

/

8

"

(16)
