RECORD SET

English

Use the following procedures to set timer recordings spanning
more than 24 hours. Perform in line 7 (default: “SAT”) and line
8 (default: “DLY”) of the screen.

Example: A Program No. 1 timer recording from 10:30 AM
on Monday to 8:30 PM on Wednesday with a recording
rate of 5 FPS

Press the [MENU] button.

The MENU indicator lights up and the

is
displayed.

Turn the jog dial to select “2.RECORD

SET” and then turn the shuttle dial

clockwise.

The screen is displayed.

Turn the jog dial to select “6.TIMER

SET” and then turn the shuttle dial

clockwise.

The screen is displayed.

Turn the jog dial to select line 7 (SAT)

and then turn the shuttle dial clockwise.

“SAT” in the “WEEK” column flashes.

Make settings in the “WEEK” and

“START” columns.

(1) Turn the jog dial to select “MON” and then turn the shuttle

dial clockwise.
“---” (hour) flashes.

(2) Turn the jog dial to select “10” (hour) and then turn the

shuttle dial clockwise.

(3) Turn the jog dial to select “30” (minutes) and then turn the

shuttle dial clockwise.

Turn the jog dial to set the end time to

“**” and then turn the shuttle dial

clockwise.

The “DLY” item on line 8 automatically changes to “TUE” (i.e.,
the day after that set on line 7) and flashes. Items that do not
need to be set are indicated with asterisks (*).

Timer recordings spanning more than 24 hours

WEEK START STOP PROGRAM FPS SET
SUN --:-- --:-- OFF 12.5 FPS OFF
MON --:-- --:-- OFF 12.5 FPS OFF
TUE --:-- --:-- OFF 12.5 FPS OFF
WED --:-- --:-- OFF 12.5 FPS OFF
THU --:-- --:-- OFF 12.5 FPS OFF
FRI --:-- --:-- OFF 12.5 FPS OFF
SAT --:-- --:-- OFF 12.5 FPS OFF
DLY --:-- --:-- OFF 12.5 FPS OFF
EXT ***** ***** OFF 12.5 FPS OFF

Line 7

MON --:-- --:-- OFF 12.5 FPS OFF

MON 10:30 --:-- OFF 12.5 FPS OFF

MON 10:30 **:** *** *****FPS ***
TUE **:** --:-- OFF 12.5 FPS OFF
