Sony IPELA NSR-100 - Manual (Page 151)

151
Chapter 5 Settings
(2) Select the monitoring layout that you want to add from the pull-
down list, and then enter how long you want it to be displayed on-
screen (in seconds).
(3) Click [OK].
To delete a Monitor Layout
Select the monitor layout you want to delete in the monitor layout list
and then click [Delete].
To change the Monitor Layout Order
Select a monitor layout in the monitor layout list and then click [Up]
or [Down] to change the order.
Comment
Enter a comment about the monitoring sequence.
5
Once you have configured all the desired settings, click [Save] in the upper-
right corner of the window.
The settings are applied.
If you want to ignore all your setting registrations, click [Discard].
User
Use the “User” settings to register users and assign permissions.
Creating a User
1
Click [User] in the tree on the left of the window.
The “User” screen appears.
