I/O Port
Pin Assignment of I/O Port
Sensor In
Alarm Out
Pin NO. SENSOR IN
1 3.3 v
2 IN_8–
3 IN_8+
4 IN_7–
5 IN_7+
6 IN_6–
7 IN_6+
8 IN_5–
9 IN_5+
10 IN_4–
11 IN_4+
12 IN_3–
13 IN_3+
14 IN_2–
15 IN_2+
16 IN_1–
17 IN_1+
18 GND
Pin NO. ALARM OUT
1 GND
2 OUT_8–
3 OUT_8+
4 OUT_7–
5 OUT_7+
6 OUT_6–
7 OUT_6+
8 OUT_5–
9 OUT_5+
10 OUT_4–
11 OUT_4+
12 OUT_3–
13 OUT_3+
14 OUT_2–
15 OUT_2+
16 OUT_1–
17 OUT_1+
18 3.3 v
