Sentry – Slant/Fin SENTRY SX-210 User Manual
Page 6
Figure 4.
Figure 6. Connecting “RECEPTACLE B” to “MALE PLUG” inside
L8148E Aquastat Box for Sentry Packaged “S” and
“SX” boilers.
Figure 5. Vent Damper Dimensions
TABLE
Figure 8. Damper Vane
Figure 9.
6
Sentry
Vent
Size
4"
5"
6"
7"
8"
A
9
5
⁄
16
"
10
5
⁄
16
"
11
5
⁄
16
"
12
5
⁄
16
"
13
5
⁄
16
"
WARNING—DANGER
Once you have begun vent damper installation procedure, DO
NOT restore electric power and gas supply until installation
and inspection have been completed (in order to prevent the
main burners from operating). DO NOT operate the boiler until
the vent damper harness "RECEPTACLE B" is plugged into
"MALE PLUG" (as described in the installation instructions),
and the vent damper installation and checkout procedures
have been completed. Failure to observe this warning may
create a hazardous condition that could cause an explosion or
carbon monoxide poisoning.
