Fan Speed Control with the EMC2102 Device

SMSC EMC2102

USER MANUAL

Revision 0.2 (09-17-07)

19

5.3.6

Register Change Summary

Table 5.2, "Register Change Summary for Experiment 3"

lists all register value changes from the

default cmf load to accomplish the tests.

Table 5.2 Register Change Summary for Experiment 3

REGISTER

NAME

ADDRESS

DEFAULT

VALUE

NEW

VALUE

COMMENT

FAN Spin Up
Configuration

53h

01h

(00000001b)

03h

SPINUP_TIME of 2.0 sec

05h

Change the LEVEL from 60% to 75%
