Instructions for the installer
52
11.6 Positioning the fastening clips
• Insert the fastening clips in each of the positions indicated by
the arrows. The clips ensure that the hob will be fixed and
centred as accurately as possible.
• To install the clips into the hob, all you have to do is insert
them horizontally into the appropriate space by applying
light pressure.
• Then turn them upwards to fix them in place.
11.7 Inserting the hob into the hole in the work surface
Be very careful when inserting the hob. If the process is not followed correctly as described, the hob may
be damaged.
• Insert the hob, resting the frame completely on the back
edge of the hole in the work surface. Do not apply pressure
to the frame as this part is very fragile and could be
damaged.
• Then lower the front of the hob until it is fully inserted.
