Technical Specifications
38
DVR
Video
Video Format
PAL or NTSC
Video Inputs 4 x Composite BNC Inputs
Video Outputs 2 x Composite BNC Outputs, 1 x VGA Out
Display Resolution NTSC: 704 x 480, PAL: 704 x 576 (Composite Video)
VGA: Up to 1400 x 900
Display Frame Rate NTSC: 30fps, PAL: 25fps
Audio
Audio Inputs
4 x RCA Audio Input
Audio Output 2 x RCA Audio Output
Recording
Compression
Format H.264
Recording Resolution NTSC: D1 (704x480), HD1 (704x240), CIF (352x240)
PAL: D1 (704 x 576), HD1 (704 x 288), CIF (352 x 288)
Recording Frame Rate (Global) NTSC: 60 fps D1, 120fps HD1, 240fps CIF*
PAL: 50fps D1, 100fps HD1, 200fps CIF*
Maximum Frame Rate per Channel NTSC: 30fps PAL: 25fps
Recording Modes Manual / Motion / Schedule / Alarm
Multiplex Operation Triplex
HDD Interface SATA
Hard Drive Support Up to 2TB
Network
LAN
Connection Yes
Network Interface RJ45
Network Protocol(s) TCP/IP. DDNS
Network Types Static IP, DHCP, PPPoE
Remote Operation Yes
General
Operating
Power DC12V
Dimensions
Weight
4 ~ 5lb (2 ~ 2.5kg) - varies by HDD installed
Backup Method USB to Flash Drive
Mouse Support 1 x USB
Remote Control 1 x Infrared Controller
Remote Battery Type 2 x AAA
* 240fps/200fps @ CIF resolution is the equivalent frame rate.
Channels can have a maximum of 30fps/NTSC or 25fps/PAL, regardless of resolution.
Thus, the DVR has a maximum frame rate of 120fps/NTSC or 100fps/PAL.
Selecting CIF will allow you to store additional footage on the hard drive,
or allow other channels to operate at a higher resolution without compromising frame rate.
