Chapter 5: Advanced Serverboard Setup
5-11
X7DBR8+ Quick Reference
Jumper Description Default Setting
J3P 3rd Power Fail Detect Open (Disabled)
JBT1 CMOS Clear (See Section 5-9)
JCF1 Compact Flash Master/Slave Select Closed (Master)
JI 2 C1/JI 2 C2 SMBus to PCI-E Slots Enable/Disable Open (Disabled)
JPA1* SCSI Controller Enable/Disable Pins 1-2 (Enabled)
JPA2/JPA3* SCSI ChA/ChB Termination En/Dis Open (Enabled)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPL1/ JPL2 JLAN1/JLAN2 Enable/Disable Pins 1-2 (Enabled)
JWD Watch Dog Pins 1-2 (Reset)
Connector Description
COM1/COM2 COM1/COM2 Serial Port/Header
FAN 1-5 Fan 1-5 Headers
J22 Floppy Disk Drive Connector
IDE#1/IDE#2 IDE Hard Drive/Compact Flash Card Connectors
JA1/JA2* SCSI Channel A & B Ports
JAR1 Alarm Reset Header
JD1 Power LED (pins1-3)/Speaker Header (pins 4-7)
JF1 Front Control Panel Connector
JL1 Chassis Intrusion Header
JLAN1/2 G-bit Ethernet Ports
JOH1 Overheat LED
JP3 Power Fail Header
JPW1 24-pin Primary ATX Power Connector
JPW2 4-pin Auxiliary Power Connector
JPW3 8-pin Processor Power Connector
JUID1 UID LED Header
JUID2 UID Switch Header
JWF1 Compact Flash Card Power Connector
JWOL Wake-on-LAN Header
JWOR Wake-on-Ring Header
LE1 PWR LED Indicator
I-SATA0 - I-SATA5 Intel Serial ATA Ports
SGPIO1/SGPIO2 SGPIO Headers
SMB System Management Bus Header
SMBUS_PS Power System Management (I
2
C) Header
USB0/1, JUSB2, JUSB3 USB0/1 Ports, USB2/3 Headers, USB4/5 Headers
*X7DBR8+ only
