Using the Control Panel
3.8
Network Menu (CLP-650N only)
This menu lets you configure the network interface card
installed in your printer according to how the network is set up.
You can upgrade the network interface card firmware, and print
the configuration. (*: the default setting)
Item Explanation
Config Network
Sets whether or not you configure the network. If
you select Yes, you can configure the TCP/IP,
Netware and AppleTalk menus.
Config TCP
Select whether you set the IP address or not.
If you select Yes, you can configure the IP
address.
If you select Yes, the IP Get Method option
appears on the display. You can select how to get
the IP address.
IP Get Method
You can set this item only when you set the
Config TCP to Yes.
• Static: You can enter an IP address,
subnetmask, and gateway manually.
• BOOTP: The BOOTP server allots an IP address
to you automatically.
• DHCP: The DHCP server allots an IP address to
you automatically.
IP Address
You can select this item only when you set IP
Get Method to Static. This item lets you enter
an IP address manually. Press the scroll button to
set the value of the 1st byte between 0 and 255,
and then press the Enter button.
Set the value for the 2nd, 3rd, and 4th byte the
same way.
Subnet Mask
You can set this item only when you set IP Get
Method to Static. This item lets you enter a
subnet mask manually. Press the scroll button to
set the value of the 1st byte between 0 and 255,
and then press the Enter button.
Set the value for the 2nd, 3rd, and 4th byte the
same way.
Options: Yes, No
Options: Yes, No
Options: Static, BOOTP, DHCP
Gateway
You can set this item only when you set IP Get
Method to Static. This item lets you enter a
gateway manually. Press the scroll button to set
the value of the 1st byte between 0 and 255, and
then press the Enter button.
Set the value for the 2nd, 3rd, and 4th byte the
same way.
AppleTalk
You can select whether or not to use the
AppleTalk for Macintosh. If you select On, you can
use the AppleTalk.
Netware
You can select whether or not to use the Netware
protocol.
If you select On, you can access the Config
Netware menu item.
In the Config Netware menu, you can specify
the frame type parameter used on your network.
Config Netware
You can set this item only when you set
Netware to On. This item lets you select
whether or not you set the frame type parameter.
Select Yes to select the frame type.
If you select Yes, the IPX Frame Type option
appears on the display.
IPX Frame Type
You can select this item only when you set
Config Netware to Yes. This item lets you
select the IPX Frame Type.
• Auto: You can set a frame type automatically.
• EN_8022: Select this value to use the IEEE
802.2 frame type.
• EN_8023: Select this value to use the IEEE
802.3 frame type.
• EN_II: Select this value to use the ETHERNET
II frame type.
• EN_SNAP: Select this value to use the SNAP
frame type.
Reset Network This item reboots the network interface card.
Default Set
This item performs a simple reset and restores
the factory default settings for the network
configuration.
Item Explanation
Options: On, Off
Options: On, Off
Options: Yes, No
Values: Auto, EN_8022, EN_8023, EN_II,
EN_SNAP
