Sierra Monitor Corporation Sentry Controller Gas Detector - Manual (Page 6)

Sentry MODBUS I/O Memory Map
March 4, 2005 Page : 5
Modbus Address Parameter Units FIX EGU
40040:0 Sensor 3: Sensor Disconnected (Trouble Bits)
40040:2 Sensor 3: Voltage Regulator Failure
40040:3 Sensor 3: Sensor Bad
40040:4 Sensor 3: Duplicate Sensor
40040:5 Sensor 3: Timer Failure
40040:6 Sensor 3: Sensor Bridge Failure (Combustibles)
40040:7 Sensor 3: Type Error
40041:0 Sensor 3: Enabled
40041:1 Sensor 3: Auto Calibration Enabled
40041:2 Sensor 3: Low Alarm Latch
40041:3 Sensor 3: Calibrated
40041:4 Sensor 3: Zone Option Enabled
40041:5 Sensor 3: Calibration Table Initialized
40041:6 Sensor 3: H
2
S Sensor Resistance too high
40041:7 Sensor 3: Operate Mode (as opposed to Warm Up Mode)
40042:0 Sensor 3: High Alarm Latch
40042:1 Sensor 3: Low Sensitivity
40042:2 Sensor 3: Sensor not Valid
40044:0 Sensor 3: Concentration % / PPM 0 - 6553.5
40050:0 Sensor 4: Sensor Disconnected (Trouble Bits)
40050:2 Sensor 4: Voltage Regulator Failure
40050:3 Sensor 4: Sensor Bad
40050:4 Sensor 4: Duplicate Sensor
40050:5 Sensor 4: Timer Failure
40050:6 Sensor 4: Sensor Bridge Failure (Combustibles)
40050:7 Sensor 4: Type Error
40051:0 Sensor 4: Enabled
40051:1 Sensor 4: Auto Calibration Enabled
40051:2 Sensor 4: Low Alarm Latch
40051:3 Sensor 4: Calibrated
40051:4 Sensor 4: Zone Option Enabled
40051:5 Sensor 4: Calibration Table Initialized
40051:6 Sensor 4: H
2
S Sensor Resistance too high
40051:7 Sensor 4: Operate Mode (as opposed to Warm Up Mode)
40052:0 Sensor 4: High Alarm Latch
40052:1 Sensor 4: Low Sensitivity
40052:2 Sensor 4: Sensor not Valid
40054:0 Sensor 4: Concentration % / PPM 0 - 6553.5
