Sierra Monitor Corporation Sentry Controller Gas Detector - Manual (Page 15)

Sentry MODBUS I/O Memory Map
March 4, 2005 Page : 14
Modbus Address Parameter Units FIX EGU
40398 Sensor 7 High Alarm Time Month
40399 Sensor 7 High Alarm Time Day
40400 Sensor 7 High Alarm Time Hr
40401 Sensor 7 High Alarm Time Min
40402 Sensor 7 Low Alarm Time Month
40403 Sensor 7 Low Alarm Time Day
40404 Sensor 7 Low Alarm Time Hr
40405 Sensor 7 Low Alarm Time Min
40406 Sensor 7 Calibration Time Month
40407 Sensor 7 Calibration Time Day
40408 Sensor 7 Calibration Time Hr
40409 Sensor 7 Calibration Time Min
40410 Sensor 7 High Conc. Time Month
40411 Sensor 7 High Conc. Time Day
40412 Sensor 7 High Conc. Time Hr
40413 Sensor 7 High Conc. Time Min
40414 Sensor 7 Low Conc. Time Month
40415 Sensor 7 Low Conc. Time Day
40416 Sensor 7 Low Conc. Time Hr
40417 Sensor 7 Low Conc. Time Min
40418 Sensor 7 Trouble Time Month
40419 Sensor 7 Trouble Time Day
40420 Sensor 7 Trouble Time Hr
40421 Sensor 7 Trouble Time Min
40422 Sensor 7 Input Value - Multiplex 0 0 - 6553.5
40423 Sensor 7 Input Value - Multiplex 1 0 - 6553.5
40424 Sensor 7 Input Value - Multiplex 2 0 - 6553.5
40425 Sensor 7 Input Value - Multiplex 3 0 - 6553.5
40426 Sensor 7 Input Value - Multiplex 4 0 - 6553.5
40427 Sensor 7 Input Value - Multiplex 5 0 - 6553.5
40428 Sensor 7 Input Value - Multiplex 6 0 - 6553.5
40429 Sensor 7 Input Value - Multiplex 7 0 - 6553.5
40430 Sensor 7 Calibration Due Days
40431 Sensor 8 High Alarm Time Month
40432 Sensor 8 High Alarm Time Day
40433 Sensor 8 High Alarm Time Hr
40434 Sensor 8 High Alarm Time Min
40435 Sensor 8 Low Alarm Time Month
40436 Sensor 8 Low Alarm Time Day
40437 Sensor 8 Low Alarm Time Hr
40438 Sensor 8 Low Alarm Time Min
40439 Sensor 8 Calibration Time Month
40440 Sensor 8 Calibration Time Day
40441 Sensor 8 Calibration Time Hr
40442 Sensor 8 Calibration Time Min
