Sentry MODBUS I/O Memory Map
March 4, 2005 Page : 3
Modbus Address Parameter Units FIX EGU
40007:0 High alarm relay latched – sensor 1
40007:1 High alarm relay latched – sensor 2
40007:2 High alarm relay latched – sensor 3
40007:3 High alarm relay latched – sensor 4
40007:4 High alarm relay latched – sensor 5
40007:5 High alarm relay latched – sensor 6
40007:6 High alarm relay latched – sensor 7
40007:7 High alarm relay latched – sensor 8
40008:0 Low alarm relay latched – sensor 1
40008:1 Low alarm relay latched – sensor 2
40008:2 Low alarm relay latched – sensor 3
40008:3 Low alarm relay latched – sensor 4
40008:4 Low alarm relay latched – sensor 5
40008:5 Low alarm relay latched – sensor 6
40008:6 Low alarm relay latched – sensor 7
40008:7 Low alarm relay latched – sensor 8
40009:0 Common high/low alarm relay latched – sensor 1
40009:1 Common high/low alarm relay latched – sensor 2
40009:2 Common high/low alarm relay latched – sensor 3
40009:3 Common high/low alarm relay latched – sensor 4
40009:4 Common high/low alarm relay latched – sensor 5
40009:5 Common high/low alarm relay latched – sensor 6
40009:6 Common high/low alarm relay latched – sensor 7
40009:7 Common high/low alarm relay latched – sensor 8
40011 Sensor 1 concentration % / PPM 0 - 6553.5
40012 Sensor 2 concentration % / PPM 0 - 6553.5
40013 Sensor 3 concentration % / PPM 0 - 6553.5
40014 Sensor 4 concentration % / PPM 0 - 6553.5
40015 Sensor 5 concentration % / PPM 0 - 6553.5
40016 Sensor 6 concentration % / PPM 0 - 6553.5
40017 Sensor 7 concentration % / PPM 0 - 6553.5
40018 Sensor 8 concentration % / PPM 0 - 6553.5
