Seagate STT8000A - Manual (Page 29)

Installation Chapter 3
STT8000A Product Manual Page 21
Pin Assignment Description Source
24 –REQ Ground N/A
25 –I/O I/O Read Host
26 GND Ground N/A
27 IORDY I/O Ready Device
28 CSEL Cable Select Device
29 DMACK DMA Acknowledge Host
30 GND Ground N/A
31 INTRQ Interrupt Request Device
32 10CS16- 16-Bit I/O Device
33 DA1 Device Address Bit 1 Host
34 PDIAG Passed Diagnostics Device
35 DA0 Device Address Bit 0 Host
36 DA2 Device Address Bit 2 Host
37 CS0- Chip Select 0 Host
38 CD1- Chip Select 1 Host
39 DASP- Device Active or Slave
Present
Device
40 Ground Ground N/A
