Seagate STT8000A - Manual (Page 15)

Specifications Chapter 2
STT8000A Product Manual Page 7
Specifications
Overview
The STT8000A provides exceptional reliability in storing large amounts of computer
data. This chapter includes the following specifications and requirements:
•
Physical specifications
•
Power requirements
•
Drive performance specifications
•
Environmental requirements
•
Reliability
•
Recommended tapes
•
Tape capacities and formats
•
Regulatory compliance
Physical specifications
The physical specifications of the STT8000A are listed in the following table.
Specification
Drive for 3.5-Inch
Mount
Drive for 5.25-
Inch Mount
Height 1.0 in/ 25 mm 1.7 in/ 43 mm
Width 4.0 in/102 mm 5.87 in/149.1 mm
Length 6.2 in/157.5 mm 6.36 in/161.5 mm
Weight 1.0 lbs/0.5 kg 1.5 lbs/0.7 kg
Figures 2-1 and 2-2 show the general dimensions of the STT8000A in 3.5-inch
configuration (without mounting brackets) and in the 5.25-inch configuration (with
mounting brackets).
2
