English – 19
ENG
MAIN MENU
System Information
Shows info and current confi guration.
Display Setup
Enable/Disable of OSD display on Main Screen.
Motion Setup
Setup for motion related settings
Function Setup
Setup for various functions such as Preset, Auto
Pan, Pattern, Scan and Schedule.
Camera Setup
Confi gure Camera related functions and data
System Setup
Confi gure for Basic system setup.
System Initialize
Initializes system confi guration and sets all data to
factory default confi guration.
SYSTEM INFORMATION
Firmware Ver.
Shows current fi rmware version of camera.
Color System
Shows current analog video system of the camera.
Protocol
Shows current Protocol for PTZ control
•
•
•
•
•
•
•
•
•
•
Baud rate Shows current Baud rate of PTZ
control.
Address Shows current Camera ID for PTZ
control.
DISPLAY SETUP
This menu defi nes Enable/Disable of OSD display on
Main Screen. If an item is set to be AUTO, the item is
displayed only when the value of it is changed.
Camera ID [ON/OFF]
PTZ Information [ON/OFF/AUTO]
Action Title [ON/OFF/AUTO]
Preset Label [ON/OFF/AUTO]
Alarm I/O [ON/OFF/AUTO]
Date/Time [ON/OFF]
Start Privacy Zone Mask
setup Menu.
PRIVACY ZONE MASK SETUP
Select area in image to mask.
Mask No. [1~8]
Select Mask number. If the selected mask has
already data, camera moves as it was set.
Otherwise, “UNDEFINED” will be displayed under
“Mask NO”.
•
•
•
•
•
•
•
•
•
•
How to use OSD Menu
ROOT MENU
EXIT
SYSTEM INFORMATION
FIRMWARE VER 1.00S36
COLOR SYSTEM NTSC
PROTOCOL SAMSUNG
BAUD RATE
9600
ADDRESS 255
BACK
EXIT
DISPLAY SETUP
CAMERA ID ON
PTZ INFORMATION AUTO
ACTION TITLE
AUTO
RESET LABEL AUTO
ALARM I/O AUTO
DATE/TIME ON
BACK
EXIT
PRIVACY ZONE
MASK NO. 1
UNDEFINED
DISPLAY
OFF
CLEAR MASK CANCEL
BACK
EXIT
