English - 73
Serial Cable(1P to 1P)(Not supplied)
Rear Panel
Auto Wall-Mount
Auto Wall - mount adjustment (Sold separately) (PS50A676)
Once the auto wall mount is installed, the position of your TV can be easily adjusted.
Entering the menu
1
Press the ▲, ▼, ◄ or ► button on your remote control.
¯
The Wall Mount Adjustment screen is displayed.
¯
If the Wall Mount Adjustment screen is not displayed
when clicking on a direction button while watching your
TV, use the menu to display that screen.
• Press the MENU button to display the menu. Press
the ▲ or ▼ button to select Setup, then press the
ENTER button.
•
Press the ▲ or ▼ button to select Wall-Mount
Adjustment, then press the ENTER button.
Remembering the Position
2
Adjust to the desired position using the ▲, ▼, ◄, ►
buttons.
¯
If you press an arrow button when no OSD is displayed
on the TV screen, the Adjustment screen appears.
¯
Press the INFO button to reset. Press the ◄ or ►
button to select Yes, then press the ENTER button.
The position is initialized to the default setting.
3
Press the blue button.
Press the ▲ and ▼ buttons to select a save mode from
either Position1, Position2 or Position3 in order to save
the current position.
To not save the current position, press the RETURN
button.
When selecting a save mode, you cannot use the
Color buttons.
4 Press
the
ENTER button to save.
¯
When Position1 is selected, the message Current
position saved as Position1 is displayed.
5 Press
the
ENTER button.
¯
The saved Position appears on the left side of the
OSD
.
Continued...
Save
Return
Move
Enter
Select a mode to Save.
Position 1
Position 3
Position 2
Wall-Mount Adjustment
Adjust
Save
Center
►
►
►
►
►
►
►
►
3
2
1
Position
Teletext Language
: --
Preference
Wall-Mount Adjustment
►
Melody : Off
Entertainment :
Off
Energy Saving
: Off
PIP
Software Upgrade
Common Interface
Setup
