Samsung SWL-4000AP User Manual
Page 81
APPENDIX
.
Explanation of Basic Configuration to use AP Manager
n Explanation of AP External Icons
DC 5V Power LED(Green), it is always on.
IEEE 802.3 Wired LAN Connection LED(Orange), it is always on.
IEEE 802.11 Wireless LAN Connection(Slot A) LED(Green), it blinks.
Status LED(Red) - firmware upgrade / error occur
n Explanation of Detailed Names and Icons of AP Manager
This “AP Manager Execution Icon” appears on Desktop(under MS-Windows) of
desktop and notebook PC.
“AP Scan” window above appears during the first execution of AP Manager and
also when [AP Scan] button is selected.
