38
⑤ A window will appear and ask you to apply new settings immediately. If you do
not want to apply new settings, select [No(N)].
⑥ If you click [Yes(Y)] button, “Password” window will appear. After you enter
the password, click [OK] button to apply. In case you select [No(N)] button,
new settings will be saved. If you want to continue applying procedure again,
click [Apply] button on “Button Bar”.
⑦ When you click [Basic] tab on “Tab Bar,” ADSL Connection Status will appear
in Dialogue Box. The connection status will show “N/A” for Access Point and
“Connected”, “Disconnected” and “Negotiating” for ADSL Setting.
⑧ Clicking [ADSL State(Connected, Disconnected, Negotiating)] button enables
you to disconnect. On the other hand, when you click the button while it is
disconnected, you can re-connect according to selected information.
Connected
Disconnected
Negotiating
