SysKonnect SK-98xx V2.0 - Manual (Page 59)

SysKonnect SK-98xx V2.0 Gigabit Ethernet Adapter
Technical Specifications 59
Technical Specifications
Network interface
standard IEEE 802.3z, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE
802.1q, IEEE 802.3, IEEE 802.3u, IEEE 802.3ac, IEEE 802.3ad
Supported buses 32- and 64-bit PCI/PCI-X slots with clock speeds from 16 MHz (PCI
33) to 66 MHz (PCI 66)
Bus width 64-bit; supports 32-bit operation in 32-bit PCI slot
RAM 128 KB RAM on-chip buffer
Flash EPROM 128 KB
Serial EEPROM Maximum size: 2 KB
EEPROM contains VPD
Power manage-
ment Advanced Power Management according to PCI Bus Power Man-
agement Interface Specification, Revision 1.1 or later and Network
Device Class Power Management Reference Specification V2.0
Safety standards Europe: EN60950 – IEC 60950 – VDE 0805
USA/Canada: cULus listed accessory (UL 60950, CSA C22.2)
International: CB certification
Safety standard
Transceiver USA: Transceiver complies with U.S. 21CFR, 1040.10, 1040.11
Approved use SK-98xx V2.0 adapters are intended for use with UL-listed Person-
al Computers
EMC standards Europe: EN55022; IEC – CISPR-22 Class B
EN 55024
USA: FCC, CFR 47 Part 15, Declaration of Conformity, Class B
Power consump-
tion SysKonnect SK-9821 V2.0 Gigabit Ethernet 10/100/1000Base-T,
RJ-45:
@ + 5V / VCC_I/O: max. 7.5W
@ +3.3V(aux)/+5V: max. 375mA
SysKonnect SK-9843 V2.0 Gigabit Ethernet 1000Base-SX, SC:
@ + 5V / VCC_I/O: max. 7.5W
Measures (max.) 167.7mm x 64.41mm
Temperature range Operation: 0°C to +50°C
Storage: -20°C to +70°C
Relative humidity Operation: 30% to 80% non-condensing
Storage: 10% to 95% non-condensing
Warranty 5 years
