50 6 Testing the Network Adapter
Reading Sensor Data
To read sensor data, proceed as follows:
1. Start the main program (see page 49).
2. Select S HOW S ENSORS in the main menu.
A separate window will be displayed for the following sensor data:
•
Temperature of the board
• Voltage on the PCI card
• Voltage on the PCI I/O lines
• Other supply voltages
In the main menu, S HOW S ENSORS changes to H IDE S ENSORS .
3. You can close the window by selecting H IDE S ENSORS in the main menu.
Other windows may be opened while this window is still open, e.g. the window displaying
the configuration data.
Reading Configuration Data
To read configuration data, proceed as follows:
1. Start the main program (see page 49).
2. Select S HOW C ONFIGURATION in the main menu.
A separate window will be displayed showing:
•
Device code (
Device
)
• Various vendor codes (
Vendor
)
• Interrupt no. (
IRQ
)
• Cache Line Size (
CLS
)
• Latency (
Lat.
)
• RAM size (
RAM
)
• PCI slot index and size (
Slot
and
Slot size
)
• PCI bus clock (
clk
)
• MAC address (
MAC Addr
)
• Port type (
PMD-Type
)
• Connector (
connector
)
• Hardware revision (
HW Rev
)
• Chip ID (
Chip Id
)
In the main menu, S HOW C ONFIGURATION changes to H IDE C ONFIGURATION .
3. You can close the window by selecting H IDE C ONFIGURATION in the main menu.
Other windows may be displayed while this window is still open, e.g. the window display-
ing the sensor data.
