Sanyo VDC-DPN9585P - Manual (Page 18)

Half-Mirror Cover
VCZ-51
Attachment
VA-50AL
In-Ceiling Bracket
VA-DK02
Heater board
VA-50H
Smoked Cover
VCZ-50
(Unit: mm)
82.5
46.0
R18.7
R151.9
R154.9
93°
0.3
167.3
162.8
22.4
8.0
42.0
3.4
M4 8 4
Wall mounting bracket
VA-50BW
Attachment
VA-50AS
0.5
4.5
22.4
41.7
83.4
45.5
ø150
22.8
22.8
(Unit: mm)
209
M6 *6-2
M24 *P-1.5
6
205
66.7
6
83.5
ø120
209
Ceiling suspension bracket
VA-50BPS
(Unit: mm)
66.7
83.5
ш7-4
ш120
M24 *P-1.5
M6 *6-2
MINIMUM LENGTH 300 3
6
ø120
MAXIMUM LENGTH 464 6
6
(Unit: mm)
for VCC-PN9575P / VCC-P9575P
/ VCC-P7575PA for VCC-PN9575P / VCC-P9575P
/ VCC-P7575PA
for VDC-DPN9585P / VDC-DP9585P
VDC-DP7585P
for VCC-PN9575P / VCC-P9575P
/ VCC-P7575PA
Ceiling suspension bracket
VA-50BPL
(Unit: mm)
M24 *P-1.5
M6 *6-2
MINIMUM LENGTH 440 3
6
ø120
MAXIMUM LENGTH 1020 6
6
83.5
ш7-4
ш120
66.7
Wall mounting
Short Ceiling mounting
Long Ceiling mounting
VCC-PN9575P
VCC-P9575P
VCC-P7575PA
p11
p15
p16
VA-50BW
VA-50BPS
VA-50BPL
VA-50AS
VA-50AS
VA-50AS
+
+
+
Model name Installation Attachment + Brackets Model name Installation Attachment + Brackets
Wall mounting
Short Ceiling mounting
Long Ceiling mounting
VDC-DPN9585P
VDC-DP9585P
VDC-DP7585P
p11
p14
p16
VA-50BW
VA-50BPS
VA-50BPL
VA-50AL
VA-50AL
VA-50AL
+
+
+
The heater board protects the camera from cold
weather. It allows the camera to operate at
temperatures as low as -30°C. (24 V AC only)
for VCC-XZ200P / VDC-DPN9585P /
VDC-DP9585P / VDC-DP7585P
for VA-50AL / VA-50AS
for VA-50AL / VA-50AS
for VA-50AL / VA-50AS
ш230
ш200
103
40
8.4
(Unit: mm)
for VDC-DPN9585P / VCC-PN9575P /
VDC-DP9585P / VCC-P9575P / VDC-DP7585P /
VCC-P7575PA / VDC-W1595VP /
VDC-D1585VP / VDC-C1575VP
17
System Chart
Specialty Camera
Network Camera
Pan-focus Camera
Camera · Lens
DVR
SSP System
Example System
Monitor
Option
