Model number codes
VA-80ME VA-80MF
In-ceiling type
(Closed type) (Open type)
VA-80F
Surface type
Applications
VA-80EX
Outdoor type
The combination of camera units and options allows the user to create tailor-made solutions. It also
simplifies the installation.
VA-CM8C
Clear dome cover
for outdoor housing
(Sold separately)
VA-CM8S
Smoked dome cover
for outdoor housing
(Sold separately)
In-ceiling bracket In-ceiling bracket
Camera unit
with clear dome cover (standard)
(Smoked dome cover [VA-CZ80] option)
Camera unit
with clear dome cover (standard)
(Smoked dome cover [VA-CZ80] option)
Camera unit
Surface cover
Outdoor housing
IP66
Rated
24 V AC / 230 V AC
VA-84S
Power supply base
VCC-MC800P
VCC-MC700P
VCC-MC600P
VCC-MC500P
VCC-MC800P
VCC-MC700P
VCC-MC600P
VCC-MC500P
VCC-MC800P
VCC-MC700P
VCC-MC600P
VCC-MC500P
24 V AC
VA-84S / 80S
Power supply base
24 V AC / 230 V AC
VA-84S / 80S
Power supply base
3 0
0 0
Model configurations example
Model name
VCC-9800EXCP
VCC-9530EFCP
VCC-9700INSP
Camera unit
VCC-MC800P
VCC-MC500P
VCC-MC700P
Power basement
VA-84S
VA-80S
VA-84S
Housing
VA-80EX
VA-80MF
VA-80F
Dome cover
VA-CM8C
VA-CZ80
+ + +
+
+
+
+
+
+
+
+
Dome cover
C Clear cover
S Smoked cover
8
7
6
5
Housing type
I N Surface cover
E M In-ceiling (closed)
E F In-ceiling (open)
E X Outdoor housing
36x, Day/night
36x, Color
30x, Day/night
30x, Color
Camera type
AC230V
AC24V
Power
P PAL
Available in Three Different Packages
Outdoor, Surface, or In-ceiling --- Select a combination that matches your needs!
