Sony HVR-Z7E - Manual (Page 135)

135
Qu
ic
k R
e
fe
re
n
ce
A HDV/DV jack (59)
B COMPONENT OUT jack (59)
C A/V OUT jack (59)
D LANC
jack
The LANC control jack is used for
controlling the tape transport of video
device and peripherals connected to it.
E
i (headphones) jack
F INPUT2 switch (13)
G INPUT1 switch (13)
H REC CH SELECT switch (13)
I INPUT2 jack (13)
J INPUT1 jack (13)
K PUSH (lens hood release) button (14)
L Cable holder (13)
M “Memory Stick Duo” slot (24)
N Access lamp (24)
O REC START/STOP button (26)
P
OPEN/EJECT lever (24)
Q LENS jack (10)
LANC
HD
V/D
V
COMPONENT OUT
LINE
INPUT2
INPUT1
MIC
MIC
LINE
MIC
MIC
qa
qs
1
9 q;
qd qf
4
5 qh qg
qj
6 7 8
2
3
Continued ,
