11
Ge
tt
in
g
S
ta
rte
d
# shows the ASSIGN BTN number.
* If your lens does not have a zoom display
function, the zoom position is not displayed on
the screen.
**Your camcorder does not display the extender
indicator when you use the extender function of
the lens.
# shows the ASSIGN BTN number.
• If the lens is not properly locked, it may come
off when in use, which may cause a serious
problem. Make sure that the lens is securely
locked. Sony recommends that you set the lens
securing tab B as illustrated.
• Press the REC START/STOP button on the
handle or the START/STOP button on the
Remote Commander to record when using a
lens that does not have a lens cable.
z Tips
• When you attach a non-Carl Zeiss lens, Sony
recommends that you adjust the black balance
with the iris closed before recording. (p. 35)
You need to adjust the flange focal length
(the distance from the lens flange to the
plane of the image along the optical axis)
when you have changed lenses.
z Tips
• Your camcorder can store flange focal length
data for ten different Carl Zeiss lenses (VCL-
412BWH/VCL-308BWH). If you remount the
lens after you have mounted ten different lenses
and adjusted their flange focal length, you need
to adjust the flange focal length for the lens even
for the Carl Zeiss lens whose flange focal length
has been adjusted.
ASSIGN BTN
LENS
L1
L2
FLANGE BACK
FOCUS DISP
FOCUS MACRO
HANDLE ZOOM
SHOT TRANSITION
STEADYSHOT
S.TRANS/F.MARK
ZOOM DISPLAY*
Extender indicator**
For the lens without the lens cable (12 Pin)
AF ASSIST
ASSIGN BTN
CAMERA
ASSIGN#
FOCUS
FOCUS INFNTY
FOCUS MACRO
ONE PUSH AF
ASSIGN BTN
LENS
L1
L2
RET
AT IRIS LMT
CAM DATA DSP (Iris value)
FLANGE BACK
FOCUS DISP
For the lens with the lens cable (12 Pin)
FOCUS MACRO
HANDLE ZOOM
SHOT TRANSITION
STEADYSHOT
S.TRANS/F.MARK
ZOOM DISPLAY
Adjusting the flange focal length (for
Carl Zeiss lens)
For the lens without the lens cable (12 Pin)
Continued ,
