Page 21
Chapter 2
Creating Device Property Files
7
pressed_buttons_image = ph1_press.png
highlighted_image = ph1_highlight.png
4. Change the indicator image locations in the following lines in
NewPhone.properties
, if they are different from the existing locations. The
network indicator location property has the following format:
netindicator.bounds =
x, y, width, height
Where x is a horizontal distance in pixels to the network’s indicator left top corner,
y is a vertical distance to the network’s indicator left top corner, width is and
indicator’s image width and height is an indicator image’s height. For example:
netindicator.image = indicator.png
netindicator.bounds = 17, 82, 19, 19
Obtain and Enter the Screen Properties
●
By measuring the image file, obtain the screen properties:
■
■
■
Note –
In the following sections, the values entered in the device property file are
assumed to be values that you have measured on the image file and are intended to
be an example.
Screen Location
Referring to the left image in
, you specify the location of the
top left corner of the screen relative to the top left corner of the device image by
two lines of the form:
screen.x =
screen.y =
●
Enter the following measured values for the screen location in
NewPhone.properties
:
screen.x = 38
screen.y = 82
