DSP resources and Mixer Auto Routing
Assigning a mixer column to a DSP
NOTE: This section assumes that Mixer Edit mode is selected (press [E] to switch between Mixer
Edit mode and Mixer Control mode) and that the I/O and DSP Assign tool has been selected for the
left mouse button by clicking on its icon:
Clicking in an empty area of a mixer column running on an SSL Soundscape Mixpander DSP with
the I/O and DSP Assign tool calls up a list of the available DSPs for that card with their current
resources usage. This list remains visible for as long as the mouse button is held down. The ticked
entry indicates the DSP that the mixer column is currently assigned to (DSP 3 in this example). The
DSP assignment can be changed by placing the mouse pointer on the entry for the chosen DSP
before releasing the mouse button:
