Rear panel, Ez s – SMC Networks 24/16 User Manual
Page 15
EZ S
WITCH
10/100
4
Rear Panel
The AC power receptacle is located on the rear panel of the
switch.
Module Ports
Link/
Act
On
The module has established a valid network
connection.
Flashing
Traffic is passing through the module.
Off
The module has not established any network
connection.
Note: All optional modules operate in full-duplex mode only.
