Chapter 3. Preparing the Library
42
The library supports arbitrated loop topology with various methods of connectivity.
Connect the other end of the cable according to your Fibre Channel connectivity as
directed in the table below and in Figure 3-11, Figure 3-12 and Figure 3-13.
Loop Connectivity Description Connect the library to...
Private loop Library and computer(s) are connected directly to each
other (direct device-to-device loop) or through a hub
(standalone loop). The Fibre Channel adapter in the host
computer or to an available port on the
hub.
Public loop The library is connected to fabric via an FL port, either
direct or via a loop. An available port on the hub.
Figure 3-11 Two-node private loop.
Figure 3-12 N-node private loop.
Spectra 10000
Server
Library
Spectra
10000
Library
Disk
Array
Server
1
Hub
Workstation
Server
2
