Appendix A. Library Specifications
122
High-Voltage Differential Differential SCSI Connectors
Pin Assignments
Pin assignments for differential 68-pin micro-SCSI connectors are listed
in the following table:
Pin
Signal
Pin
Signal
1
+DB(12)
35
-DB(12)
2
+DB(13)
36
-DB(13)
3
+DB(14)
37
-DB(14)
4
+DB(15)
38
-DB(15)
5
DB(P1)
39
-DB(P1)
6
GND
40
GND
7
+DB(0)
41
-DB(0)
8
+DB(1)
42
-DB(1)
9
+DB(2)
43
-DB(2)
10
+DB(3)
44
-DB(3)
11
+DB(4)
45
-DB(4)
12
+DB(5)
46
-DB(5)
13
+DB(6)
47
-DB(6)
14
+DB(7)
48
-DB(7)
15
+DB(P)
49
-DB(P)
16
DIFFSENS
50
GND
17
TERMPWR
51
TERMPWR
18
TERMPWR
52
TERMPWR
19
RESERVED
53
RESERVED
20
+ATN
54
-ATN
21
GND
55
GND
22
+BSY
56
-BSY
23
+ACK
57
-ACK
24
+RST
58
-RST
