Chapter 3. Preparing the Library
35
Possible Logical Library Configuration 2
In the example below, the division of slots is not
equal between host machines. In this example, a UNIX host running Legato is allocated
two tape drives and 30 slots; a Windows NT machine running Legato is allocated the
remaining 10 tape slots and two tape drives.
Figure 3-6 Possible Logical Library Configuration 2.
30 Slots
10 Slots
Drive 1
Drive 2
Drive 3
Drive 4
UNIX Host
Windows NT Machine
SCSI Bus 2
SCSI Bus 1
