Product overview, Overview of the ek 2000 diversity receiver – Sennheiser EK 2000 User Manual
Page 7
6
Product overview
Product overview
Overview of the EK 2000 diversity receiver
³
Headphone output (
PHONES
),
3.5 mm jack socket, lockable
·
Line output (
AF OUT
),
3.5 mm jack socket, lockable
(the ground contact is used by
antenna II)
»
Antenna I
¿
Operation and battery status
indicator, red LED
(lit =
ON
,
flashing =
LOW BATT
)
´
RF signal indication, green LED
(lit =
RF
)
²
Charging contacts
¶ SET
button
º
̆
/
̄
rocker button
(
UP
/
DOWN
)
¾
Battery compartment
µ
Battery compartment cover
(metal)
¸
Battery compartment catches
¹
Infra-red interface
Ƹ ON
/
OFF
button
with ESC function (cancel)
ƹ
Display panel, backlit in orange
»
¿
´
¶
²
Ƹ
¹
²
ƹ
¾
µ
¸
¸
º
³
·
