JVC DR-MH50S - Manual (Page 65)

EN
65
EDITING
L-2 Select Setting
Set AL-2 SELECTB to the appropriate mode depending on the type
of appliance connected to the unit’s [L-2 IN/DECODER] connector.
1
Perform steps 1 and 2 of AL-1 Output And L-1 Input SettingB
( A pg. 64).
2
Press selection keys to select AL-2 SELECTB, then press ENTER.
3
Press selection keys
to select the
appropriate setting,
then press ENTER.
4
Press SET UP to
complete the setting.
* The boldface settings below indicate the settings at your purchase.
8
L-2 SELECT ^ VIDEO / S-VIDEO / SAT VIDEO / SAT S-VIDEO /
DECODER
Select AVIDEOB or AS-VIDEOB to use this unit as the recording
deck with the player connected to the [L-2 IN/DECODER]
connector, or to use the satellite receiver connected to the [L-2 IN/
DECODER] connector.
VIDEO :
If a connected appliance’s output is compatible only with regular
video signals, set to
AVIDEOB.
S-VIDEO :
If a connected appliance’s output is compatible with Y/C
signals, set to
AS-VIDEOB. You can obtain high-quality picture.
(For connection, be sure to use a 21-pin SCART cable that is
compatible with the Y/C signal.)
Select ASAT VIDEOB or ASAT S-VIDEOB to view a satellite
programme with the TV set while the unit is turned off. ( A pg. 68)
SAT VIDEO :
If a connected satellite receiver’s output is compatible only with
regular video signals, set to
ASAT VIDEOB.
SAT S-VIDEO :
If a connected satellite receiver’s output is compatible with Y/C
signals, set to
ASAT S-VIDEOB. You can obtain a high-quality
S-VHS picture. (For connection, be sure to use a 21-pin SCART
cable that is compatible with the Y/C signal.)
DECODER :
To use a decoder connected to the [L-2 IN/DECODER] connector.
NOTES:
● If you have a satellite receiver or a decoder connected to the [L-2
IN/DECODER] connector, be sure to set
AL-2 SELECTB back to
appropriate mode after editing.
● If you are not connecting a satellite receiver or a decoder to the
[L-2 IN/DECODER] connector, leave
AL-2 SELECTB set to
AVIDEOB.
● When AL-2 SELECTB is set to ASAT VIDEOB and ASAT
S-VIDEO B, ASATB appears on the TV screen or front display
panel instead of AL-2B.
● If AL-1 OUTPUTB is set to ASCART S-VIDEOB, it is not possible
to set AL-2 SELECTB to ADECODERB or ASAT VIDEOB.
● If AL-1 OUTPUTB is set to ASCART RGBB, it is not possible to set
AL-2 SELECTB to ADECODERB or ASAT S-VIDEOB.
● If AL-1 OUTPUTB is set to ACOMPONENTB and AL-2 SELECTB
to ASAT VIDEOB, ASAT S-VIDEOB or ADECODERB, be sure to
connect the [L-1 IN/OUT] connector with a TV.
● If AL-2 SELECTB is set to ASAT S-VIDEOB, be sure to set AL-1
OUTPUT B to ASCART S-VIDEOB.
F-1 Input Setting
Set AF-1 INPUTB to the appropriate mode depending on the
connector (VIDEO or S-VIDEO) being used on the front panel.
1
Perform steps 1 and 2 of AL-1 Output And L-1 Input SettingB
( A pg. 64).
2
Press selection keys to select AF-1 INPUTB, then press
ENTER.
3
Press selection keys
to select the
appropriate setting,
then press ENTER.
4
Press SET UP to
complete the setting.
* The boldface settings below indicate the settings at your purchase.
8
F-1 INPUT ^ VIDEO / S-VIDEO
VIDEO :
When connecting an appliance to the [VIDEO] input connector,
set to
AVIDEOB.
S-VIDEO:
When connecting an appliance to the [S-VIDEO] input
connector, set to
AS-VIDEOB.
DVD VIDEO SET UP HDD/DVD SET UP FUNCTION SET UP INITIAL SET UP
REC/PLAY SET UP DISPLAY SET VIDEO IN/OUT
SELECT WITH @ THEN PRESS [ENTER] ENTER
SELECT
SET UP
EXIT
PRESS [SET UP] TO EXIT
MONITOR TYPE
F-1 INPUT
L-1 OUTPUT
L-1 INPUT
L-2 SELECT
4:3LB
VIDEO
VIDEO
SCART VIDEO
VIDEO
VIDEO
SAT VIDEO
SAT S-VIDEO
DECODER
S-VIDEO
DVD VIDEO SET UP HDD/DVD SET UP FUNCTION SET UP INITIAL SET UP
REC/PLAY SET UP DISPLAY SET VIDEO IN/OUT
SELECT WITH @ THEN PRESS [ENTER] ENTER
SELECT
SET UP
EXIT
PRESS [SET UP] TO EXIT
MONITOR TYPE
F-1 INPUT
L-1 OUTPUT
L-1 INPUT
L-2 SELECT
4:3LB
VIDEO
VIDEO
SCART VIDEO
VIDEO
VIDEO
S-VIDEO
