The back panel of the recorder provides the connectors that you use to wire the recorder to
all the other components and equipment that you may use.
Depending on the installation setup that you use, you may not use some of these
connectors, but they are provided to support any desired setup.
Tighten the back panel coaxial cable connections only by hand. Using a
wrench may over-tighten the connections, causing damage. Such damage is
not covered by the Limited Warranty.
S
ATELLITE
A
NT.
I
N
Connect the coaxial cable from the satellite antenna to the recorder using
this connection.
VHF/UHF A
NT.
I
N
(RF
OR
VHF C
ONNECTION
)
Connect your broadcast TV antenna or cable TV connection here.
A
CCESSORY
J
ACK
The
Accessory Jack
is reserved for future use.
