User and
Installation Guide
P
OWER
L
IGHT
The POWER light illuminates when the recorder is turned ON.
This light flashes when the recorder memory contains
unread mail messages.
R
EC
L
IGHT
The REC light illuminates while a tape is being recorded.
This light blinks during Instant Timer Recording (ITR).
P AUSE
L
IGHT
The PAUSE light illuminates when recording or playback is paused.
T IMER
L
IGHT
The TIMER light illuminates to show that the recorder's timer has
been set to record a program automatically.
EP L
IGHT
The EP light illuminates during recording or playback in the EP
(Extended Play) mode.
I
NFO
B
UTTON
The Info button displays information about a program or about the
system, depending on what you are currently viewing.
M
ENU
Press the Menu button to open the Main Menu .
U
P
/D
OWN
/L
EFT
/R
IGHT
A
RROW
B
UTTONS
These buttons change the channel numbers move the highlight when in
a menu or other screen.
From a program, the
Up/Down buttons change channels; the Left/Right
buttons display other menus.
S
ELECT
B
UTTON
Press the Select button to select a highlighted menu option and
perform that function.
