Jackson Gas Heated Door-Type Dishmachines Tempstar GP - Manual (Page 24)

CONTROL BOX ASSEMBLY - FRONT VIEW
22
ITEM QTY DESCRIPTION MFG NO.
01 1 Control Box Cover Decal 9905-021-91-15
02 1 Rinse Thermometer, 48" Lead 6685-111-68-48
03 1 Power Light (Red) 5945-504-07-18
04 1 Screw, 10-32 X 3/8" Phillips Truss Head 5305-173-12-00
05 1 Delime ( Manual Wash) Switch 5930-301-21-18
06 1 On / Off Power Switch 5930-011-49-55
07 1 Delime/Normal Decal 9905-011-34-96
08a 1 Timer, 220v/60, 8 cam 5945-021-94-11
08b 1 Timer, 110v/60, 8 cam 5945-002-01-73
09 1 Cycle Light (Green) 5945-504-08-18
10 1 Timer Mounting Bracket 5700-021-34-54
11 8 Micro Switch 5945-111-68-49
12 1 Wash Thermometer, 96" Lead 5700-111-68-49
01 02 04 05 06 07 08 10 12 03 09 11
