JVC GR-DVX48A - Manual (Page 99)

EN
99
For Connectors
AV
Video output : 1 V
(
p-p
)
, 75
Ω
, analogue
Video input (GR-DVX78 only) : 0.8 V ( p-p ) – 1.2 V ( p-p ) , 75
Ω
, analogue
Audio output : 300 mV (rms), 1 k
Ω
, analogue, stereo
Audio input (GR-DVX78 only) : 300 mV (rms), 50 k
Ω
, analogue, stereo
Headphone output
(GR-DVX78 only)
: Stereo
DV
Input/output : 4-pin, IEEE 1394 compliant
AC Adapter AP-V10A, AP-V10EA or AP-V10ED
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Output : DC 11 V , 1 A
Dimensions (W x H x D) : 59 mm x 31 mm x 84 mm
Weight : Approx. 140 g (not including Power Cord)
Jack Box
For General
Dimensions (W x H x D) : 52 mm x 22 mm x 73 mm
Weight : Approx. 35 g
For Connectors
USB (GR-DVX78 only) : Type B
EDIT (GR-DVX78 only) : ø3.5 mm, 2-pole
S-Video
Output : Y : 1 V ( p-p ) , 75
Ω
, analogue
C : 0.29 V
(
p-p
)
, 75
Ω
, analogue
Input (GR-DVX78 only) : Y : 0.8 V ( p-p ) – 1.2 V ( p-p ) , 75
Ω
, analogue
C : 0.2 V
(
p-p
)
– 0.4 V
(
p-p
)
, 75
Ω
, analogue
JLIP (GR-DVX49/DVX48 only) : ø3.5 mm, 4-pole
PC (DIGITAL PHOTO)
(GR-DVX49/DVX48 only)
: ø2.5 mm, 3-pole
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
