INDEX Jack Box
1 USB Connector [USB]
(GR-DVX78 only) ................................. ੬ pg. 74
PC Connector [PC (DIGITAL PHOTO)]
(GR-DVX49/DVX48 only) ....................
੬ pg. 74
2 S-Video Output Connector
[S-VIDEO] ................................ ੬ pg. 22, 57, 70
3 •EDIT Connector [EDIT]
(GR-DVX78 only) ..............................
੬ pg. 70
Connect the editing cable when performing
Random Assemble Editing .........
੬ pg. 69 – 73
•J Terminal
[JLIP (Joint Level Interface Protocol)]
(GR-DVX49/DVX48 only) ..................
੬ pg. 70
Connect to a JLIP-compatible camcorder or VCR
to control it from the computer using the
provided Software.
Connect the editing cable when performing
Random Assemble Editing .........
੬ pg. 69 – 73
3
2
1
3
2
1
(GR-DVX78: CU-V506) (GR-DVX49/DVX48: CU-V505)
