29
From the remote control:
You can also make adjustments the following way from the
remote control.
Set the mode selector to “AUDIO/TV/VCR/DBS.”
1 Press TEST TONE to check the speakers’ output
balance.
• On the TV screen, “TEST TONE” appears. The
indicator corresponding to the speaker appears while a
test tone comes out of the speakers.
EX.:
• On the display, “TEST L” starts flashing, and a test tone
comes out of the speakers in the following order:
2 Adjust the speaker output levels.
To adjust the left front speaker level (L), press
FRONT L +/–.
To adjust the right front speaker level (R), press
FRONT R +/–.
To adjust the center speaker level (C), press
CENTER +/–.
To adjust the left surround speaker level (LS), press
SURR L +/–.
To adjust the right surround speaker level (RS), press
SURR R +/–.
To adjust the surround back speaker level (SB), press
S.BACK +/–.
To adjust the subwoofer level (SW), press SUBWFR +/–.
3
Press TEST TONE again to stop the test tone.
NOTES
• You can adjust the speaker output levels without the test tone.
• No test tone comes out of the speakers and no speaker
indication appears on the TV screen corresponding to the
speaker which is set to “NO” in the speaker setting (see
page 21).
• No test tone is available when the headphone is in use or
“DVD MULTI” is selected.
NOTES
• To return to “TOP MENU,” press MENU on the remote control.
• To exit from menu operations, press MENU on the remote
control when “TOP MENU” appears. On the front panel, press
ADJUST when a menu except “TOP MENU” appears.
• The adjustment item previously selected can be shown on the
TV screen by pressing ADJUST on the front panel when the
receiver is in normal operation mode.
Button indications on the screen
The buttons for operating the menu are shown on the TV
screen. You can operate the menu with these buttons.
Adjusting the items
When performing the basic settings viewing the indications
on the display, the indications are slightly different from what
is shown on the on-screen display.
This is because of the limited number of characters shown
on the display.
Ex.: • “SUBWOOFER: +10” is shown as “SUBWFR +10” on
the display.
• “BASS BOOST: ON” is shown as “B BOOST ON” on
the display.
Adjusting speaker output level
• SUBWOOFER LEVEL (subwoofer output level),
• FRONT L LEVEL (left front speaker output level),
• FRONT R LEVEL (right front speaker output level),
• CENTER LEVEL (center speaker output level),
• SURROUND L LEVEL (left surround speaker output level),
• SURROUND R LEVEL (right surround speaker output level),
• SURROUND BACK LEVEL (surround back speaker output
level)
You can adjust the speaker output levels.
Adjust all the speakers’ output levels so that you can listen to the
sounds from all the speakers at the same level.
• Once you have made an adjustment, it is memorized for each
source.
Adjustable range: –10 (dB) to +10 (dB) (in 1 step intervals)
Initial setting: 0 (dB) for all speakers
NOTES
• If you have selected “NO” for a speaker (see page 21), the
output level for the corresponding speaker is not adjustable.
• While using the headphones, you can adjust only the left and
right front speakers’ output level.
Usable buttons and their functions
Usable buttons and their functions
TOP MENU
5
SETTING MENU
ADJUST MENU
∞
:ENTER :EXIT
SUBWOOFER LEVEL
SUBWOOFER :
2 0 3
23:OPERATE :BACK
TEST TONE
SW+1 L+5 C 0 R-3
LS+5 RS+5
SB+5
C
L
SW
R
SB
LS RS
2
1, 3
