Specifications
Designs & specifications are subject to change without notice.
Amplifier
Output Power
At stereo operation:
Front channels:
100 W per channel*, min. RMS, driven into
8
Ω at 1 kHz with no more than 0.8% total
harmonic distortion. (IEC268-3)
At surround operation:
Front channels:
100 W per channel*, min. RMS, driven into
8
Ω at 1 kHz with no more than 0.8% total
harmonic distortion.
Center channel:
100 W*, min. RMS, driven into 8
Ω at 1 kHz,
with no more than 0.8% total harmonic
distortion.
Surround channels: 100 W per channel*, min. RMS, driven into
8
Ω at 1 kHz, with no more than 0.8% total
harmonic distortion.
*Measured on AC 110V, 127 V, 220 V and 240 V.
Audio
Audio Input Sensitivity/Impedance (1 kHz):
DVD, DVD MULTI, DBS, VCR, TV:
260 mV/47 k
Ω
Audio Input (DIGITAL IN)* :
Coaxial: DIGITAL 1 (DVD):
0.5 V(p-p)/75
Ω
Optical: DIGITAL 2/3 (DBS/TV):
–21 dBm to –15 dBm
(660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency—32 kHz, 44.1 kHz, 48 kHz).
Audio Output Level: VCR:
250 mV
Signal-to-Noise Ratio (’66 IHF/DIN):
DVD MULTI:
87 dB/62 dB
Frequency Response (8
Ω):
DVD, DBS, VCR, TV:
20 Hz to 20 kHz (±1 dB)
Tone Control:
Bass (100 Hz):
±10 dB ±2 dB
Treble (10 kHz):
±10 dB ±2 dB
Bass Boost:
+4 dB ± 1 dB at 100 Hz
Video
Video Input Sensitivity/Impedance (1 kHz):
Composite video:DVD, DBS, VCR:
1 V(p-p)/75
Ω
S-Video:DVD, DBS, VCR:
(Y:luminance):
1 V(p-p)/75
Ω
(C:chrominance):
0.286 V(p-p)/75
Ω
Component video:DVD, DBS:
(Y:luminance):
1 V(p-p)/75
Ω
(P
B
/P
R
):
0.7 V(p-p)/75
Ω
Video Output Level/Impedance (1 kHz):
Composite video: VCR, MONITOR OUT:
1 V(p-p)/75
Ω
S-Video: VCR, MONITOR OUT:
(Y:luminance):
1 V(p-p)/75
Ω
(C:chrominance):
0.286 V(p-p)/75
Ω
Component video: MONITOR OUT:
(Y:luminance):
1 V(p-p)/75
Ω
(P
B
/P
R
):
0.7 V(p-p)/75
Ω
Synchronize:
Negative
FM tuner (IHF)
Tuning Range:
87.50 MHz to 108.00 MHz
Usable Sensitivity:
Monaural:
12.8 dBf (1.2 µV/75
Ω)
50 dB Quieting Sensitivity:
Monaural:
16.0 dBf (1.7 µV/75
Ω)
Stereo:
37.5 dBf (20.5 µV/75
Ω)
Stereo Separation at REC OUT:
35 dB at 1 kHz
AM tuner
Tuning Range:
522 kHz to 1 629 kHz
General
Power Requirements:
AC 110 V/127 V/220 V/230 V – 240 V,
adjustable with the voltage selector,
50 Hz/60 Hz
Power Consumption:
100 W (at operation)
5 W (in standby mode)
Dimensions (W x H x D):
435 mm x 69.5 mm x 330.5 mm
Mass:
6.5 kg
