XA4200, XA4300
9
4 Speakers + 2 Subwoofers
Important
When running a subwoofer and two
full-range speakers together (Tri-
mode operation), high and low pass
filters must be used. Failure to install
these filters may damage your amp
and/or speakers.
Freq.
Speaker Impedance
Hz
2 OHMS
4 OHMS
8 OHMS
L
C
L
C
L
C
80
4.1mH
1000
µF
8.2mH
500
µF
15mH
250
µF
100
3.1mH
800
µF
6.2mH
400
µF
12mH
200
µF
130
2.4mH
600
µF
4.7mH
300
µF
10mH
150
µF
200
1.6mH
400
µF
3.3mH
200
µF
6.8mH
100
µF
250
1.2mH
300
µF
2.4mH
150
µF
4.7mH
75
µF
400
.8mH
200
µF
1.6mH
100
µF
3.3mH
50
µF
600
.5mH
136
µF
1.0mH
68
µF
2.0mH
33
µF
800
.41mH
100
µF
.82mH
50
µF
1.6mH
26
µF
1000
.31mH
78
µF
.62mH
39
µF
1.2mH
20
µF
1200
.25mH
66
µF
.51mH
33
µF
1.0mH
16
µF
1800
.16mH
44
µF
.33mH
22
µF
.68mH
10
µF
4000
.08mH
20
µF
.16mH
10
µF
.33mH
5
µF
Capacitor
C
Inductor
L
4
Ω
X-OVER
LPF
HPF
FULL
X-OVER
LPF
HPF
FULL
FRONT
REAR
2
Ω
=
2
Ω minimum
4
Ω
=
4
Ω minimum
2
Ω
RF
RF
LF
LF
–
–
+
+
BRIDGE
BRIDGE
RR
RR
LR
LR
2
Ω
2
Ω
2
Ω
4
Ω
