JVC DLA-SH7NL - Manual (Page 23)

23
Ⅵ Connection Example During Two-Screen Mode
Ⅵ Connection Example During Four-Screen Mode
NOTE:
● Depending on your DVI-D cable, the signal may attenuate and the image become unstable.
● Use of DVI-D cables compliant with the DDWG standard is recommended.
OPERATE I/ B
DVI 3
USB
LAN
RS-232C
STANDBY/ON
CONTROL
LAMP
WARNING DVI 4
DVI 1
DVI 2
DVI-D Cable (Sold Separately)
To DVI Terminal
Desktop Computer
To DVI Terminal
Laptop Computer
OPERATE I/ B
DVI 3
USB
LAN
RS-232C
STANDBY/ON
CONTROL
LAMP
WARNING DVI 4
DVI 1
DVI 2
DVI-D Cable
(Sold Separately)
To DVI Terminal
Desktop Computer
To DVI Terminal
Laptop Computer
To DVI Terminal
To DVI Terminal
